Circuit Realizations


In total, 457 circuit realizations are available at RevLib. You can download all circuits at once using the following link:
Download all circuits
Alternatively, single access to every circuit is provided below. This list can also be refined according to a respective gate library.



    Lib. lines gates costs File Pic. Ref. Realizes
1 MCT+P 10 1538 44702 Download realization No picture available MDS:2005 Hidden Weighted Bit (over 9 variables)
2 MCT+P 10 1535 44653 Download realization No picture available MDS:2005 Hidden Weighted Bit (over 9 variables)
3 MCT+P 12 748 7013 Download realization Show realization MDS:2005 Hidden Weighted Bit (over 8 variables)
4 MCT+P 12 633 16522 Download realization Show realization MDS:2005 Hidden Weighted Bit (over 8 variables)
5 MCT+P 12 610 14691 Download realization Show realization MDS:2005 Hidden Weighted Bit (over 8 variables)
6 MCT+P 10 27 117 Download realization Show realization MDS:2005 rd53
7 MCT+P 15 21 98 Download realization Show realization MDS:2005 rd84
8 MCT+P 13 21 94 Download realization Show realization MDS:2005 sym9
9 MCT+P 5 16 63 Download realization Show realization   Hidden Weighted Bit (over 4 variables)
10 MCT+P 10 15 75 Download realization Show realization MDS:2005 rd53
11 MCT+P 7 15 62 Download realization Show realization MDS:2005 sym6
12 MCT+P 9 14 64 Download realization Show realization MDS:2005 rd73
13 MCT+P 10 8 120 Download realization Show realization MDS:2005 rd53
14 MCT+P 10 8 36 Download realization Show realization MDS:2005 rd53
15 MCT+P 5 6 19 Download realization Show realization MDS:2005 Check 4 modulo 5
16 MCT+P 5 5 16 Download realization Show realization   Decod24
17 MCT+P 5 4 7 Download realization Show realization WLDG:2008 Check 4 modulo 5
18 MCT+P 6 3 9 Download realization Show realization   1-bit Adder / rd32
19 MCT+P 6 2 8 Download realization Show realization   1-bit Adder / rd32
