RevLib is an online resource for benchmarks within the domain of reversible and quantum circuit design
Universit├Ąt Bremen References Cite RevLib Acknowledgements About RevLib


Circuit Realizations


In total, 457 circuit realizations are available at RevLib. You can download all circuits at once using the following link:
Download all circuits
Alternatively, single access to every circuit is provided below. This list can also be refined according to a respective gate library.



    Lib. lines gates costs File Pic. Ref. Realizes
1 MCF 4 166 4170 Download realization Show realization MDS:2005 Hidden Weighted Bit (over 7 variables)
2 MCF 5 65 1171 Download realization Show realization MDS:2005 Hidden Weighted Bit (over 6 variables)
3 MCF 5 24 248 Download realization Show realization MDS:2005 Hidden Weighted Bit (over 5 variables)
4 MCF 5 11 81 Download realization Show realization MDS:2005 Hidden Weighted Bit (over 4 variables)
5 MCF 5 3 21 Download realization Show realization MDS:2005 Decod24 with enable
6 MCF 3 1 7 Download realization Show realization FT:82 Fredkin gate

legend


 back
