Circuit Realizations


In total, 457 circuit realizations are available at RevLib. You can download all circuits at once using the following link:
Download all circuits
Alternatively, single access to every circuit is provided below. This list can also be refined according to a respective gate library.



    Lib. lines gates costs File Pic. Ref. Realizes
1 NCT 15 256 768 Download realization No picture available D. Michael Miller A 64-bit adder
2 NCT 15 128 384 Download realization No picture available D. Michael Miller A 32-bit adder
3 NCT 15 116 368 Download realization Show realization MDS:2005 A form of integer adder.
4 NCT 15 64 192 Download realization Show realization D. Michael Miller A 16-bit adder
5 NCT n.a. 46 90 Download realization Show realization MDS:2005 0410184
6 NCT 15 32 96 Download realization Show realization D. Michael Miller An 8-bit adder
7 NCT 5 25 49 Download realization Show realization MDS:2005 Hamming Code (over 7 variables)
8 NCT n.a. 20 120 Download realization Show realization D. Michael Miller Ternary Counter
9 NCT 5 5 5 Download realization Show realization MDS:2005 Graycode (over 6 variables)
